Product Details
- Place of Origin: CHINA
- Brand Name: akesimu
- Model Number: 63-315
- Weight: 1.000 kg
| Specification | Related data please correspondmto the root diagram | |||||||
| d1 | d2 | D | L | I1 | I2 | I3 | K1 | K3 |
| 63 | 63 | 87 | 175 | 70 | 100 | 105 | 30 | 60 |
| 75 | 75 | 91 | 175 | 70 | 100 | 105 | 25 | 55 |
| 90 | 90 | 118 | 200 | 80 | 100 | 120 | 25 | 70 |
| 110 | 110 | 135 | 225 | 90 | 100 | 135 | 20 | 65 |
| 125 | 125 | 140 | 250 | 100 | 123 | 150 | 20 | 80 |
| 160 | 160 | 140 | 350 | 140 | 140 | 210 | 60 | 135 |
| 200 | 200 | 140 | 360 | 180 | 160 | 180 | 90 | 90 |
| 250 | 250 | 140 | 440 | 220 | 185 | 220 | 110 | 110 |
| 315 | 315 | 140 | 560 | 280 | 220 | 280 | 170 | 170 |
can be customized. Please mark specification in the order.
